U.2 PCIe PT33

U.2 PCIe PT33 is an enterprise SSD pairing with 3D TLC. Taking advantage of high-speed PCI-Express 3.0 x4 32Gb/s interface and up to 10K endurance, U.2 PCIe PT33 greatly enhances computing performance and responsiveness on application launch speed and file loading time for heavy loading server and time-critical AI and IoT applications.

FEATURES

  • PCIe Gen3x4 U.2 with NVMe 1.3 supported
  • Read/Write speeds of up to 2116/1340MB/s
  • Random Performance of up to 188K/211K IOPS
  • Industrial Micron 3D TLC, up to 10K P/E Cycles
  • LDPC ECC for improved data integrity
  • End-to-end data path protection with CRC parity, better safe and data guard features
  • Featuring HMB (Host Memory Buffer), SLC caching and dynamic write acceleration
  • Built-in OCP/OVP Protection
Interface PCIe Gen 3 X4
Form Factor U.2
Controller SMI SM2263EN
Flash Type 3D TLC (Original Micron B17, 10K P/E cycle)
Max. Channel 4
Density 128GB~2TB
Sequential R/W (MB/sec, max.) 2116/1340
Operating Temperature 0°C~+70°C/-25°C~+85°C/-40°C~+85°C
Max. Power Consumption 5.82W (12Vx485mA)
Dimension (LxWxH/mm) 100x70x9.3
Operating Voltage 12V±5%
Storage Temperature -55°C~+95°C
Security ✓(AES 128/256 Encryption)
✓TCG Opal 2.0 compliant
✓Built-in H/W SHA256 and TRNG
External DRAM Buffer ✓
Thermal Sensor ✓
NVMe 1.3 ✓
Vibration 20G (7~2KHz)
Shock Resistance 1500G@0.5ms
MTBF >3 million hours
